Blumer, Atlas 110

Données générales:

Whatsapp

Description:

• Full Automatic line of High Die Cutter for Cards (Business, Phone, Loyalty, Membership), Labels, tickets
• ST-18.02 Strip stock feeder
• SE-18.2 Infeed and Cross Cutter with Automatic Program
• D-18 Die Cutting Punch Unit with 2 chases
• PB-18.1 Banding machine with delivery
• Strip length min./max. : 350/1130 mm
• Strip width min./max. : 45/180 mm
• Precut label size min. : 25x45 mm
• Precut label size max. : 150x180 mm
• Die cut size min. : 20x41 mm
• Die cut size max. : 145x175 mm
• Stack heigh min./max. : 45x125 mm
• Min. trim per side for die cut : 2 mm
• Intermediate trim cut : 3 mm / 22 mm
• Height of cutting die : 60 - 100 mm
• Mecanical Speed : 10 - 15 strokes per minute
• Die Cut Pressure : 4 - 5 Tons
• Banding machine, width : 25 mm
• Machine is controled with program and screen
• Elecrical datas : 380V, 50 Hz, 6.8 KW, 16 Amp.
• Air supply required : 6 bars dry air (30 - 45 m3/h) incl. 30% reserve
• Dimensions : 4900 x 3900 mm
• Weight : 2.400 kg
